GNSS systems
Trimble R780
Freedom to work your way.
The Trimble® R780 GNSS receiver allows you to choose your configuration and scale up by adding additional features. With robust GNSS positioning technologies, trust this ultra-durable receiver to boost your productivity and flexibility in any environment.
![geo-product-r780-pim-image-800x960](http://images.ctfassets.net/1nvkn1423yot/6b3vommgXvNeOMwe2uHpac/2aca5943c2c4d943897c30944960c37e/geo-product-r780-pim-image-800x960.png)
Benefits and performance
Unleash maximum accuracy
With industry-leading Trimble ProPoint® technology, you can trust the R780 receiver to deliver precise and reliable results in challenging GNSS environments every time.
![man surveying in forest](http://images.ctfassets.net/1nvkn1423yot/3mTn4FKtZnWIhbtV66cLQQ/43c6bb15b52a15bb0744a0b77bc43128/geo-r780-productpage-2x2topright-benefits-520x320.jpg)
![man surveying in pond](http://images.ctfassets.net/1nvkn1423yot/4zXKYrjwUiJOygCeoJI3FC/e7ff5de4ccdce392b25b992360624ab7/geo-r780-productpage-2x2bottomleft-benefits-520x320.jpg)
Stake out with confidence
Quickly and safely stake out or measure points without the need to level the pole with Trimble TIP™ technology.
![Surveyor walking with R780 on shoulder](https://images.ctfassets.net/1nvkn1423yot/7lxAynrSzTZyteHKP72jmZ/ed5eee975b9660907e6b3d964e113125/geo-r780-productpage-keyfeatures-720x720.jpg?fm=jpg&fl=progressive&w=50&h=50&q=90)
Configurations
Base & rover, rover or base
8 mm H/15 mm V
Max. precision
IP68/MIL-STD
Ultra-rugged
Features and capabilities
![Licensing that works for you](https://images.ctfassets.net/1nvkn1423yot/6yHMLRlpyITYWbyszG5Uas/8274c7aa383ee1ed63b2ed3bfe155418/geo-r780-surveyor-base-station-unboundedcard-370x247.jpg?fm=jpg&fl=progressive&w=50&h=50&q=90)
Licensing that works for you
![Stake out with efficiency](https://images.ctfassets.net/1nvkn1423yot/4ppNXflLXpDcTOZw7kExIq/7c885cf10058f6285024001b0b3271ca/geo-r780-surveyor-pole-tilted-unboundedcard-370x247.jpg?fm=jpg&fl=progressive&w=50&h=50&q=90)
Stake out with efficiency
![Unbeatable GNSS corrections](https://images.ctfassets.net/1nvkn1423yot/5V8903dEHReTS2bHpdfbEc/0830f29848067bd59cd48573a12678af/geo-r780-surveyor-remote-location-unboundedcard-370x247.jpg?fm=jpg&fl=progressive&w=50&h=50&q=90)
Unbeatable GNSS corrections
![Keep your work moving](https://images.ctfassets.net/1nvkn1423yot/m9drKOMu1mpyN0WMz1bE4/7e5bced1110d87ac9af98a54c1a01515/geo-r780-surveyor-on-hill-unboundedcard-370x247.jpg?fm=jpg&fl=progressive&w=50&h=50&q=90)
Keep your work moving
![surveyor adjusting the pole](https://images.ctfassets.net/1nvkn1423yot/6FztVMJcauay53MO10LayG/2410ba9ce34dab2aa5ccc148c369aa22/geo-r780-productpage-industries-2400x730.jpg?fm=jpg&fl=progressive&w=50&h=50&q=90)
Industries and applications
The future of your work.
Trimble facilitates high quality, productive workflows and data exchange, driving value for a global, diverse user base.
Product summary
Trimble R780
Bringing precision to challenging survey projects.
Product
Specifications
Configurations
Base & rover, rover or base
Real-time kinematic
8 mm H/15 mm V
TIP positioning performance
RTK + 8 mm + 0.5 mm/° tilt
CenterPoint RTX
2 cm H/3 cm V
Ultra-rugged
IP68/MIL-STD-810G
Dual-band UHF Radio
450/900 MHz
Skip comparison of 6 items | ||||||||||
Max. Precision | Channels | Antenna | UHF Radio | RTX Compatible | xFill | Memory | Cellular | Satellites | Additional Features | |
---|---|---|---|---|---|---|---|---|---|---|
Trimble R980Trimble R980 | 8 mm H/15 mm V | 672 | Integrated | Receive & transmit 450/900 MHz | Yes | Yes | 9 GB | 4G | GPS, GLONASS, Galileo, BeiDou, NavIC, QZSS, SBAS | ProPoint, TIP Tilt Compensation |
Trimble R12iTrimble R12i | 8 mm H/15 mm V | 672 | Integrated | Receive & transmit 450 MHz | Yes | Yes | 6 GB | 3.5G | GPS, GLONASS, Galileo, BeiDou, NavIC, QZSS, SBAS | ProPoint, TIP Tilt Compensation |
Trimble R12Trimble R12 | 8 mm H/15 mm V | 672 | Integrated | Receive & transmit 450 MHz | Yes | Yes | 6 GB | 3.5G | GPS, GLONASS, Galileo, BeiDou, NavIC, QZSS, SBAS | ProPoint |
Trimble R780Trimble R780 | 8 mm H/15 mm V | 672 | Integrated | Receive & transmit 450/900 MHz | Yes | Yes | 9 GB | External | GPS, GLONASS, Galileo, BeiDou, NavIC, QZSS, SBAS | ProPoint, TIP Tilt Compensation |
Trimble R580Trimble R580 | 10 mm H/20 mm V | 336 | Integrated | Receive 450 MHz | Yes | Yes | 256 MB | External | GPS, GLONASS, Galileo, BeiDou, SBAS, QZSS | ProPoint |
Trimble R2Trimble R2 | 10 mm H/20 mm V | 220 | Integrated | Receive 450 MHz | Yes | No | 48 MB | External | GPS, GLONASS, Galileo, BeiDou, SBAS, QZSS | — |
